Mini Small Forklift Electric 2ton
Rated Capacity: 2000kg
Lift Height: 3000 mm
Products Description
2 Ton Electric Forklift (Li-Ion) FB20
Rated Capacity: 2000kg
Lift Height: 3000 mm
The FB20 electric forklift is standard-fitted with Heding high-performance lithium batteries, boasting extended service life, a 5-year warranty, zero emissions, and maintenance-free operation. With a rapid 1.5-2 hour full-charge capacity, it perfectly adapts to multi-shift operations, ensuring continuous efficiency in intensive material handling scenarios.
FB20 electric forklift large LCD display offers real-time visualization of operational status, integrating fault self-diagnosis and misoperation alarm functions to enable precise equipment monitoring. The LMH three-gear power adjustment system allows flexible mode switching based on work conditions, while the optional steering speed control reduces rollover risks through intelligent dynamics, balancing efficiency and safety.
Designed for maintenance convenience, FB20 electric forklift battery cover opens nearly 90° and detachable side panels simplify battery replacement and circuit checks, minimizing downtime. The four-point stability structure enhances operational balance, while the responsive electric drive ensures agile maneuvering in tight spaces, combining safety with precise control for optimal performance.
The 2 ton electric forklift stands out for balancing eco-friendliness, operational efficiency, and cost savings, making it an ideal solution for businesses prioritizing sustainable operations, safety, and long-term profitability. Its adaptability to diverse industries-from retail logistics to heavy manufacturing-cements its role as a leading material handling tool in the modern industrial landscape.



Product details
|
Model |
|
FB20 |
|
Rated Capacity |
kg |
2000 |
|
Load Center Distance |
mm |
500 |
|
Power Type |
|
Electric |
|
Wheel Base |
mm |
1500 |
|
Wheel Number(Front/Rear) |
|
2×/2 |
|
Front Tread |
mm |
970 |
|
Rear Tread |
mm |
950 |
|
Tyre(Front) |
|
7.00-12-12PR |
|
Tyre(Rear) |
|
18X7-8PR |
|
Front Overhang |
mm |
468 |
|
Mast Tilting Angle,Front/Rear |
|
6/12 |
|
Height With Mast Retraction |
mm |
1995 |
|
Free Lifting Height |
mm |
150 |
|
Max.Lifting Height |
mm |
3000 |
|
Max.Height After Lifting |
mm |
4045 |
|
Overall Guard Height |
mm |
2098 |
|
Fork Size:Length X Width X Thickness |
mm |
1070×100×40 |
|
Overall Length(Fork Excluded) |
mm |
2353 |
|
Overall Width |
mm |
1170 |
|
Turning Radjus |
mm |
2172 |
|
Ground Clearance Of Mast |
mm |
110 |
|
Ground Clearance Of Wheel Base Center(Loaded) |
mm |
105 |
|
Right Angle Stacking Aisle Width (Pallet 1000×1000Mm),Clearance 200Mm |
mm |
4040 |
|
Right Angle Stacking Aisle Width (Pallet 1200×1200Mm),Clearance 200Mm |
mm |
4240 |
|
Lateral Fork Adjustment Max./Min |
mm |
1038/200 |
|
Travelling Speed (Loaded/Unloaded) |
km/h |
12/14 |
|
Lifting Speed (Loaded/Unloaded) |
mm/s |
320/450 |
|
Lowering Speed |
mm/s |
<600 |
|
Gradeability (Loaded) |
% |
12 |
|
Self Weight |
Kg |
4214 |
|
Battery Voltage /Capacity |
V/Ah |
80/202 |
|
Battery Weight |
Kg |
715 |
|
Driving Motor Power-60 Minutes |
Kw |
11 |
|
Lifting Motor Power(S315%) |
Kw |
12 |
|
Driving Motor Control Mode |
|
Full AC |
|
Lifting Motor Control Mode |
|
Full AC |
|
Service Brake/Parking Brake |
|
Hydraulic /Mechanical |
|
Hydraulic System Working Pressure |
Mpa |
17.5 |
With technological innovation, our product configuration and parameters will continue to change without notice;
if there is any doubt, the specific confirmation of our international trade sales shall prevail;
