A 3.5-ton diesel forklift is a robust piece of equipment designed for heavy lifting and tough jobs. With its sturdy build and powerful engine, it can efficiently handle large loads, making it an indispensable tool in various industries. Unlike electric forklifts, which are best suited for indoor use, diesel forklifts excel outdoors and in challenging terrains.
|
Model |
|
FD35 |
||
|
Power Type |
|
Diesel |
||
|
Rated Capacity |
kg |
3500 |
||
|
Load Centre |
mm |
500 |
||
|
Lift Height |
mm |
3000 |
||
|
Fork Size(L×W×T) |
mm |
1070×125×50 |
||
|
Mast Tilt Angle(F/R) |
Deg |
6°/12° |
||
|
Front Overhang (Wheel center to fork face) |
mm |
485 |
||
|
Ground Clearance(Bottom of mast) |
mm |
140 |
||
|
Turning Radius (outside) |
mm |
2570 |
||
|
Max.Gradeability (No load/Full load) |
% |
20 |
||
|
Wheelbase |
mm |
1800 |
||
|
Service weight |
kg |
4700 |
||
|
Overall Dimension |
Length to face of fork(Without fork) |
mm |
2835 |
Overall Dimension |
|
Overall Width |
mm |
1230 |
||
|
Mast Lowered Height |
mm |
2150 |
||
|
Mast Extended Height(With backrest) |
mm |
4175 |
||
|
Overhead Guard Height |
mm |
2110 |
||
|
Speed |
Travel (Full load) |
km/h |
20 |
Speed |
|
Lifting (Full load) |
mm/s |
440 |
||
|
Tire |
Front |
mm |
28×9-15-12PR |
Tire |
|
Rear |
mm |
6.50-10-10PR |
||
|
Battery |
Voltage/Capacity |
V/Ah |
12/80 |
Battery |
|
Engine |
Model |
4JG2PE-01 |
A495BPG-517 |
|
|
Manufacture |
ISUZU |
XINCHAI |
||
|
Rated output/r.p.m. |
kw |
46/2450 |
42/2650 |
|
|
Rated torque/r.p.m. |
N·m |
184/1600-1800 |
174/1800-2000 |
|
|
No.of Cylinder |
4 |
4 |
||
|
No.of Cylinder |
mm |
95.4x107 |
95x105 |
|
|
Displacement |
cc |
3059 |
2980 |
|
|
Fuel Tank Capacity |
L |
70 |
70 |
|
|
Transmission |
Type |
Hydraulic |
Hydraulic |
|
|
Stage(FWD/RVS) |
1/1 |
1/1 |
||
Features of 3.5 Ton Diesel Forklift
Wide view mast
Wide-view mast gives the operator and enhanced forward visibility,which adds great to the efficiency and safety of operator.
Powerful engine
The powerful engine ensures our trucks high handling performance and offers an intrinsical safety and efficient operation.
Solid overhead guard
Specially designed solid overhead guard provides additional security for the operator.
Reliable instruments
The instruments offer an easy access to the working condition of the truck,thus makes handling process more efficient and safe.
Ergonomics seat
Designed according to ergonomic principles,makes operation much comfortable and also relieves the fatigue caused by long time continuous operation.
Super low and non-slip step
Supper low and non-slip make operating convenient and safe.
High Efficiency: The 3.5 ton diesel forklift provides efficient material handling capacity, which increases productivity and reduces downtime. Its powerful engine and fast lifting speed make cargo loading and unloading fast and smooth, saving valuable time.
Versatility: With its sturdy design and high load-bearing capacity, the 3.5-ton diesel forklift can handle a variety of materials and is suitable for various industries such as logistics, manufacturing, and construction. It fits easily through tight spaces and narrow aisles, ensuring optimum efficiency in any workspace.
Cost-effective: Investing in a 3.5 ton diesel forklift is a cost-effective solution for businesses. Its low fuel consumption and minimal maintenance requirements help reduce operating costs in the long run. In addition, its durability ensures a longer service life, providing a good return on investment and making it the most repurchased model by a wide range of customers.
Type of Forklift 4 Ton Diesel
Manual Forklifts
Ideal for light, infrequent use in confined spaces. They are nimble and easy to maneuver but lack the power needed for heavy-duty tasks.
01
Gas-Powered Forklifts
Known for their high power output, these forklifts are suitable for both indoor and outdoor applications. However, they emit fumes that may require adequate ventilation indoors.
02
LPG Forklifts
Offer a blend of power and efficiency, featuring lower emissions than gasoline models. Their dual usability makes them a popular choice across different sectors.
03
Diesel Forklifts
Built for demanding conditions, diesel models excel in outdoor environments. They boast superior power and fuel efficiency, ideal for construction and agriculture.
04
Electric Forklifts
Operate on batteries, providing quiet and emission-free performance, making them perfect for indoor use in warehouses and distribution centers.
05
Applications of 3.5 Ton Diesel Forklift
Manufacturing
Efficiently manages raw materials and finished products, enhancing workflow and productivity.
Warehousing
Perfect for stacking and transporting goods, optimizing storage space and organization.
Distribution
Ensures smooth handling of goods in logistics and supply chain operations.
Construction
Suitable for moving heavy building materials on-site, ensuring efficient operations.
Metals Industry
Ideal for lifting and transporting heavy metal components with precision.
Paper Products and Packaging
Handles bulky and heavy packaging materials effectively.
Precast Concrete
Provides stable lifting and movement of concrete elements.
Wood Industry
Manages large and heavy wooden materials with ease.
The primary function of any forklift is to lift and transport loads. A 3.5-ton diesel forklift can lift a substantial amount of weight, specifically up to 3,500 kilograms (7,716 pounds). This makes it suitable for handling heavy pallets, large crates, and various bulk materials.
However, it's crucial to understand that the lifting capacity is influenced by several factors. The center of gravity of the load, the height at which the load is lifted, and the forklift's own balance play significant roles. For instance, if the load's center of gravity is closer to the forklift's mast, the machine can lift heavier weights safely.
Custom made Forklift 4 Ton Diesel
Customizing a 4 ton forklift can enhance its functionality and adaptability to specific operational needs. Many manufacturers offer color customization options, allowing businesses to align equipment with branding or safety color codes. Replaceable parts, such as forks and tyres, can be tailored to suit particular load types and terrains.
Pairing the forklift with complementary accessories, like side shifters or fork positioners, improves precision and efficiency. For example, a side shifter enables lateral movement of loads, facilitating easier placement in tight spaces. Integrating advanced technologies, such as telematics systems, provides real-time data on forklift performance, aiding in proactive maintenance and operational optimization.
Operating a 3.5-ton diesel forklift comes with inherent risks, making safety a top priority. Ensuring that operators are adequately trained and certified is the first step towards safe forklift operations. Training should cover essential topics such as load handling, maneuvering techniques, and emergency procedures.
Additionally, regular safety inspections should be conducted to identify and address potential hazards. This includes checking the brakes, lights, and warning systems to ensure they are in proper working condition.
Maintenance Tips
Maintaining your 3.5-ton diesel forklift is crucial for ensuring its longevity and optimal performance. Regular maintenance tasks include checking and changing the oil, inspecting the air filters, and ensuring the cooling system is functioning correctly.
It's also essential to monitor the tire pressure and condition, as well-maintained tires contribute to better stability and fuel efficiency. Regularly greasing the moving parts and inspecting the hydraulic system for leaks can prevent unexpected breakdowns and costly repairs.
